Keithley 500 Series Measurement and Control System

500 Series Measurement and Control System

Series 500 Data Acquisition System family: 500A, 500P, 556
   500 Series Measurement and Control System 10-slot 500A-904-01D
   500A - AC Power
   500P - DC Power "P" for Portable
   556 GPIB Measurement and Control System 10-slot

System 570 Data Acquisition Workstation 570-901-01 missing
Model 575 Measurement and Control System 4-slot 575-901-01 Rev. C
Model 576 High Speed Data Logging System GPIB based Uses 575 enclosure

IBM INterface or IBIN
IBIN-A / -LP Interface Card ISA and Low Power ISA 501-910-01D
IBIN-PS/2 Interface Card Microchannel 501-911-01B

@602B.ADF uCMDB-64 ["uC" is Micro Channel] Metrabus!
    Metrabus used a 50-pin ribbon cable, 500 Series used a DB25.

500 Series Modules [most datasheets]

Software for the 500 Series includes Soft500, Asyst, RTMDS, ViewDAC, Easyest.

NOTE: The Model 575 came AFTER Soft500 and Quick500.Some features are not supported. When other manuals refer to Soft/Quick 500, use KDAC500 unless otherwise noted.

KDAC500 Software Manual [IBM]
KDAC500/I BASICA
KDAC500/B Borland Turbo C [2.0] and Turbo Pascal [5.0 and 5.5]
KDAC500/M M$ C [5.0/5.1], QC [1.0/2.0], QB [4.0/4.5],QP [1.0] and FORTRAN [5.0]
Soft500 6.20 ver. 6.20
Quick500 2.20 ver 2.20
ASYST 4.01 [requires a key]

System 570 Data Acquisition Workstation [Images from "Blue Ridge Surplus"]

570 Front

Notice this is a "System 570"

570 Open

NOTE: there are four pre-punched holes for BNC / Banana Jacks above the "Keithley System 570" on the front of the system.

There appears to be a discrete board, 570-182-02A just to the right of the ADC80-12.

570 Lid

570 Rear

575 Measurement and Control System Images from besttestus

575 Front

575 Open

575 Lid

575 Rear
